Narrow Diffuser 45°

The Narrow Diffuser is perfect for installation in compact spaces where standard air grilles or deflectors won’t fit. Ideal for under-window placement, it ensures efficient defrosting and fog prevention.

With a 60mm connection, it easily connects directly to Air 2D heaters.

For Air 4D heater installations, we recommend to connect at least two Narrow Diffusers, using a Y-shape adapter (Assy DE041) or a combination of one Regular Grille (Assy AT2-G30D60-BK), Flange (Assy ATR2-FD60-BK) and one Narrow Diffuser, to ensure enough airflow and prevent overheating.

The kit includes:

• Body
• Front Grill
• 2x M5x35 Screws DIN 7991
• Cut-out Template
• Guideline sheet

This diffuser comes with DIN 7991 M5x35 screws for mounting surfaces from 0,5 to 24mm in thickness. For thicker surfaces, longer DIN 7991 M5 screws can be used.

Installation guidelines:
EN
